PROX5 EME RELEASE VERSION 4.1
Achieve compliance with relevant safety limit regulations for electromagnetic energy emissions and with industry codes of practice applicable to communication installations globally. Network owners/operators and licensees must meet certain obligations during design and commissioning of these installations.
Is a complete RF EME prediction modelling tool that includes a 3D drafting interface, antenna data, model visualisation and report generator.
This comprehensive solution provides RF design engineers with the ability to visualise complex RF EME fields in a 3D environment applicable to a communication installation.
ProX5 EME delivers a comprehensive set of tools and features with unrivalled flexibility:
A built-in drafting interface for creating 2D drawings or 3D models of communication installations
Access to an extensive and fully customisable library of antenna models
Calculation and assessment of accumulative electromagnetic emissions
Visualisation of RF EME exclusion zones in accordance with limits specified in international standards
Customisable reporting templates for producing compliance documentation
What’s new in Version 4.1?
Adaptive EME Clearance Display (AECD)
The Adaptive EME Clearance Display (AECD) provides ProX5 EME users with the ability to quickly identify any EME encroachment into areas requiring a specific EME clearance distance, e.g. general public accessible rooftops, balconies, footpaths etc. Subject to varying site compliance requirements, predefined clearance distances can be configured to any 3D modelled surface and applied to nearby exclusion zones. The result displays a solid colour plot on the selected 3D modelled surface directly relating to the predefined distance between the targeted surface and the selected exclusion zone. The AECD allows the user to view this critical compliance information within the 3D model view without the need for additional input.
